Overview
The Robustel R1520 OG IP67 Rated Outdoor Router offers rugged Wi-Fi access. It’s perfect for events, campuses, and indoor deployments.
About 50% of the enclosure space is available for customers to add electronics, offering a semi-bespoke solution for outdoor industrial deployments. OEM branding of the enclosure is possible for high-volume projects.
Some of the advanced features include:
Smart Roaming A unique network selection algorithm that intelligently selects networks when using 3G/4G roaming SIM cards – providing maximum reliability.
RobustVPN is a flexible hosted VPN service, enabling global inbound connections to the router and connected devices.
Power over Ethernet
Ethernet Port 0 supports PoE-PD to make installation easy – just a single M12-terminated cable is required to get power + data to and from the box.
RCMS (Robustel Cloud Manager Service)
Very high-quality Microsoft Azure based router management platform available for simple estate management. Basic version completely free – advanced functions are pay as you go.
- IP67 ingress protection withstanding water, dust, and other extreme weather conditions
- Space inside the enclosure allows users to add their own specific electronics.
- Globally certified*
- Supports dual-SIM cellular, Wi-Fi and Ethernet
- Fully programmable router
- RCMS – free, high quality cloud platform for remote management
- Supports SMS commands for remote configuration/recovery in fault conditions
- Captive Portal function optional
- VPN Support includes OpenVPN, IPSEC, Wireguard + more
- Custom branding for high volume projects
Specifications
| Cellular Interface | |
| Number of antennas | 2 |
| Connector | M16, N female |
| SIM | 2, Mini-SIM or eSIM (Optional) |
| Ethernet Interface | |
| Number of external ports | 1 x 10/100 Mbps Ethernet supporting 802.3af/at PoE-PD (ETH0 only) |
| Connector | M12 A-coded, 8PIN |
| Â Â Â Number of internal ports | 4 x 10/100 Mbps Ethernet |
| Magnet isolation | 1.5 KV |
| protection | |
| Wi-Fi Interface | |
| Number of antennas | 2 |
| Connector | M16, N female |
| Standards | 802.11 b/g/n, supports AP and Client modes |
| Frequency bands | 2.4 GHz |
| Security | WEP, WPA, WPA2 |
| Encryption | 64/128 AES, TKIP |
| Data speed | 2 x 2 MIMO, 300 Mbps |
| App Center (Available Apps for RobustOS) | |
| Apps* | L2TP, PPTP, DMVPN, VRRP, QoS, Captive Portal, |
| WLAN Multi AP, SNMP, Language, RCMS | |
| *Request on demand. For more Apps please visit www.robustel.com. | |
| Â | |
| Power Supply and Consumption | |
| Connector | M12 A-coded PoE-PD or optional DC via 3-pin connector |
| Input voltage via optional DC | 9 ~ 36 V DC |
| Physical Characteristics | |
| Ingress protection | IP67 |
| Housing & Weight | Plastic, 2008g including R1520, excludes antennas and mounting hardware |
| Dimensions | 310 x 245 x 93.4 mm |
| Installation | Wall mounting and pole mounting |
| Operating Temperature | -25 ~ +70 °C |
| Storage Temperature | -40 ~ +85 °C |
| Relative Humidity | 5 ~ 95% RH |
